Wire Tension Meter, Hand-held Tensiometer for Fibers, Wires, Optical fibe, Range 0~0.44Lbf

Specifications Model: LTTS-200 Tension Range: 0~0.2kgf; 0~200gf; 0~1.96N; 0~0.44Lbf Resolution: 0.001kgf; 1gf; 0.001N; 0.001Lbf Accuracy: ±1.0% or better Measuring Principle: Strain gauge Measuring Frequency: 16 msec (62.5 samples / sec) Sensing Roller: Deflection of Sensing Roller ( max. ) 0.2 mm Overload Capacity: 150 % of Full Scale Temperature Coefficient: Zero : less than ±0.3% FS/ °C Span : less than ±0.01% FS/ °C Display: Blue Back light LCD Display Update Rate: 0.5 , 1.0 , 2.0 or 4.0 seconds , selectable Memory System: Current Value , Max. Value , Peak Value , Min Value Overrange Indicator: Buzzer Alarm Power Off: 10 Minutes Auto , Manual Data Output: USB Roller Material: Stainless Steel ( Standard ) Maximum Speed: 2000 m/min Power Supply: 4 x 1.5 AAA( UM-4 ) Battery Operation Temperature: 0 ~ 40 °C Operation Humidity: <80 % Weight: 400 g Size: Main Unit : 149 x 70 x 30 mm Sensor : 102 x 81 x 34 mm

• It employs the ''three-roller principle'' of tension test.
• With 4 measurement unit for selection, N, kg, lb, g.
• Current Value, Max. Value, Peak Value, Min Valuevcan be displayed at the same time.
• With 10 minutes auto power off and manual power off.
• The Meter takes 62 tension measurements per second and displays the average of these measurements.
